Incorporating Antiretroviral Resistance Testing Into Clinical Practice

  • Authors: Author: Richard T. D'Aquila, MD
Start Activity

Target Audience and Goal Statement

This activity is intended for physicians and other healthcare professionals involved in the care of HIV-infected patients.

Identification of the presence of drug resistance by means of genotypic or phenotypic resistance assays can help a healthcare provider select a combination of antiretrovirals that is likely to suppress HIV-1 replication (ie, "active drugs" to which that patient's virus population is not cross-resistant). Knowing when and how to use resistance testing in clinical practice will lead to better clinical management of HIV-1-infected patients.

Upon completion of this activity, participants will be able to:

  1. Explain the methodologies used by genotypic and phenotypic antiretroviral resistance assays.
  2. Discuss the advantages and disadvantages of phenotypic and genotypic assays for antiretroviral resistance.
  3. Describe the findings of prospective clinical trials of antiretroviral resistance testing.
  4. Summarize current guidelines on the clinical use of antiretroviral resistance testing.


  • Richard D'Aquila, MD

    Infectious Disease Unit and AIDS Research Center, Massachusetts General Hospital, Boston, Massachusetts.


    Disclosure: Richard T. D'Aquila, MD, has disclosed that he has received honoraria and grants for educational activities from Agouron, Bristol-Myers Squibb, and Visible Genetics, Inc. He has also received honoraria from Gilead and ViroLogic, and has served as a consultant for Virco.

Accreditation Statements

    For Physicians

  • Medical Education Collaborative, a nonprofit education organization, is accredited by the Accreditation Council for Continuing Medical Education (ACCME) to provide continuing medical education for physicians.

    Medical Education Collaborative designates this educational activity for a maximum of 1.5 hours in Category 1 credit towards the AMA Physician's Recognition Award. Each physician should claim only those hours of credit that he/she actually spent in the educational activity.

    Contact This Provider

    For Nurses

  • This educational activity for 1.8 contact hours is provided by Medical Education Collaborative.

    Provider approved by the California Board of Registered Nursing, Provider Number CEP-12990 for 1.8 contact hours.

    Florida BN Provider Number: FBN-2773

    Contact This Provider

For questions regarding the content of this activity, contact the accredited provider for this CME/CE activity noted above. For technical assistance, contact [email protected]

Instructions for Participation and Credit

There are no fees for participating in or receiving credit for this online educational activity. For information on applicability and acceptance of continuing education credit for this activity, please consult your professional licensing board.

This activity is designed to be completed within the time designated on the title page; physicians should claim only those credits that reflect the time actually spent in the activity. To successfully earn credit, participants must complete the activity online during the valid credit period that is noted on the title page.

Follow these steps to earn CME/CE credit:

  1. Read the target audience, learning objectives, and author disclosures.
  2. Study the educational content online or printed out.
  3. Online, choose the best answer to each test question. To receive a certificate, you must receive a passing score as designated at the top of the test. Medscape encourages you to complete the Activity Evaluation to provide feedback for future programming.
You may now view or print the certificate from your CME/CE Tracker. You may print the certificate but you cannot alter it. Credits will be tallied in your CME/CE Tracker and archived for 5 years; at any point within this time period you can print out the tally as well as the certificates by accessing "Edit Your Profile" at the top of your Medscape homepage.

The credit that you receive is based on your user profile.


Incorporating Antiretroviral Resistance Testing Into Clinical Practice: Overview of HIV-1 Resistance Assay Methods


Overview of HIV-1 Resistance Assay Methods

Resistance assays use different technologies that provide complementary information about antiretroviral resistance. The 2 different types of drug resistance tests available are assays for genotype and phenotype.[1,2] Genotype assays provide information about viral mutations that may result in changes in viral susceptibility to particular drugs or classes of drugs. Phenotype assays directly quantitate the level of susceptibility of a patient's virus sample to specific drugs in vitro. The values measured from the patient sample are compared with values measured from a standard wild-type (WT) reference strain. The degree of phenotypic resistance is the difference in susceptibility to a particular drug between the patient sample and the reference strain. Both genotype and phenotype testing methods require the use of polymerase chain reaction (PCR) technology to amplify the HIV-1 genes of interest (PR and RT) from patients' plasma samples. However, there are numerousdifferences between these 2 resistance testing methods. One methodologic approach, the other, or both may be preferable in certain situations.[1,2]


Genotypic resistance assays use state-of-the-art DNA sequencing methods to examine the RT and PR regions of the HIV-1 genome for all possible resistance-associated mutations. However, some genotypic methods (line-probe assay or chip-based) interrogate only a limited subset of the positions in which resistance mutations may occur; these limited tests may be less appropriate for clinical use as an adjunct to managing the use of various antiretroviral combinations.[1,2] They do have some advantages over sequencing assays that may lead to a useful clinical niche with further development, however: they are cheaper, faster, and better able to detect minority subpopulations (to 10% or less). These features may prove advantageous for use of a line probe assay in screening, for example, in certain clinical settings.

The major limitation of genotype assays lies in the clinical interpretation of the detected mutation patterns, given the complexity of available data and the ongoing acquisition of new data (discussed further below).

The results of a genotype assay are reported in the form of the resistance mutations identified, described above in the section "How Mutations Are Designated." Some test reports may also include an interpretation of the degree of resistance conferred by the particular mutation pattern to certain drugs based on published data or presented as in vitro and/or in vivo data.

Viral genome sequencing can be performed using kits such as the TRUGENE HIV-1 Genotyping Kit, by Visible Genetics, Inc. (VGI), or the ViroSeq HIV-1 Genotyping System, by Applied Biosystems, Inc. (ABI). Some testing laboratories have developed their own assays, which are referred to as "home-brew" assays. The TRUGENE HIV-1 Genotyping Kit became the first kit to be approved by the Food and Drug Administration (FDA), in September 2001.

The retail cost of a genotype assay is approximately $400-$500 per sample, and results are generated in 1-4 weeks, with most laboratories providing results in 2 weeks.[1-3] It is likely that most clinical laboratories offering viral load testing will eventually adopt FDA-approved resistance tests, which may eliminate or reduce the time required for shipping and processing of specimens. As a result, a significant improvement in reporting time and the possibility of local specimen testing, including local prioritization of certain specimens (eg, needle-stick source specimens), should make genotypic resistance testing more timely and affordable for patient management. The use of FDA-approved kits should also provide an advantage in improving standardization and consistency of mutation detection and interpretation.


Phenotypic assays use recombinant virus composed of a patient's virus PR and RT genes, which are inserted into a standard reference strain of virus. The recombinant virus is then tested in vitro for the amount of each particular drug needed to inhibit virus replication by 50% (50% inhibitory concentration, IC50), relative to the amount of drug needed to inhibit a reference strain of virus. Results are reported in the form of the fold change in drug susceptibility relative to a reference strain of HIV-1 (Figure 2).[1,2] An increase in IC50, increase in resistance, and decrease in susceptibility are each different ways of expressing the fact that more drug is needed to inhibit the patient's virus in vitro. relative to the reference virus. Two recombinant virus phenotypic assays are available from commercial laboratories in the United States: PhenoSense HIV from ViroLogic, Inc. (South San Francisco) and Antivirogram from Tibotec-Virco GroupNV (Belgium). A third assay is commercially available in Europe.

While genotypic assays search for mutations in the viral genome that may have an impact on viral susceptibility to certain drugs, phenotypic assays directly measure the impact of various drug concentrations on viral replication. Figure 2 shows the relationship between the percent inhibition of viral replication (Y-axis) of WT and mutant strains of HIV and increasing drug concentrations (X-axis). The shift to the right of the sigmoidal concentration curve of the mutant HIV strain illustrates that greater concentrations of drug are needed (IC50) in order to provide the same level of inhibition relative to the WT strain. The major limitation now is in clinical interpretation of an IC50: what fold change in resistance predicts escape from drug inhibition in vivo. This is still under study and varies by drug, with data now available for only a few drugs. The "clinical cut-off" for an IC50 is also probably best used if it can be related to interpatientdifferences in blood levels of the drug in question (discussed further below).

  • The cost of a phenotype assay is approximately $750-$900 per sample and the average turnaround time is 2-8 weeks.[1,2] The reporting time for a phenotype result is generally longer than that for a genotype result. Due to the complexity and biological hazard of the technology, as well as the level of infrastructure and operator expertise required, it is unlikely that clinical reference laboratories or local hospital laboratories will be able to adopt recombinant virus phenotypic assays.

  • slide

    Figure 2.

    Relationship between in vitro drug concentration and percent inhibition of wild-type and mutant strains of HIV.

    (Enlarge Slide)
